Getting Started

dotMARC needs two separate Entra app registrations: do not reuse one for both purposes.

1. Mailbox access (app-only)​

  1. App registrations → New registration, name it e.g. dotmarc-mailbox.

  2. API permissions → add Microsoft Graph Application permission Mail.Read, then grant admin consent.

  3. Certificates & secrets → create a client secret.

  4. Restrict this app's mailbox access via an Exchange Application Access Policy. Exchange requires the policy scope to be a security principal (for example a mail-enabled security group), not the mailbox itself. Create a dedicated group for the DMARC reports mailbox, add that mailbox to the group, and then scope the policy to the group:

    Connect-ExchangeOnline -Organization <your-tenant>

    $group = New-DistributionGroup -Name "dotMARC DMARC Reports Scope" -Type Security -Alias dotmarc-dmarc-reports
    Add-DistributionGroupMember -Identity $group.Identity -Member "[email protected]"

    New-ApplicationAccessPolicy -AppId <client-id> -PolicyScopeGroupId $group.ObjectId -AccessRight RestrictAccess -Description "dotMARC: restrict to DMARC reports mailbox only"

    If you already have the mail-enabled security group, use its ObjectId instead of the mailbox address. Do not pass the mailbox address directly to -PolicyScopeGroupId.

2. Dashboard sign-in (delegated)​

  1. App registrations → New registration, name it e.g. dotmarc-dashboard.
  2. Authentication → add a Web platform redirect URI: https://<your-deployment-host>/signin-oidc.
  3. Certificates & secrets → create a client secret. Microsoft.Identity.Web wires this app up via the standard confidential-client authorization-code flow, so the token exchange after sign-in needs this secret even though the app itself is only used for interactive sign-in.
  4. No API permissions needed beyond the default User.Read.

Configure​

Set via environment variables (double-underscore nesting):

VariableDescription
Graph__ClientIdMailbox app registration's client ID
Graph__TenantIdYour tenant ID
Graph__ClientSecretMailbox app registration's client secret
Graph__MailboxAddressThe shared mailbox address receiving DMARC reports
Graph__PollIntervalSecondsDefault 300
EntraId__TenantIdYour tenant ID
EntraId__ClientIdDashboard app registration's client ID
EntraId__ClientSecretDashboard app registration's client secret
ConnectionStrings__DotMarcPostgreSQL connection string; defaults to Host=localhost;Database=dotmarc;Username=dotmarc;Password=dotmarc
InitialAdmins__EmailsComma-separated list of email addresses granted the Admin role the very first time the app starts with no existing access grants either a genuinely fresh install, or this app's first deploy of the permissions feature to an existing live environment. Only takes effect while the UserAccess table is empty; harmless to leave set afterwards.

:::danger[Set InitialAdmins__Emails before deploying this feature] Authorization is deny-by-default: with no existing access grants, the fallback policy locks out every user, including the operator, unless InitialAdmins__Emails seeds at least one Admin grant on that first startup. If you deploy without it, recovery requires direct database access to insert a UserAccess row pointing at a locked Admin role. :::

Run​

$env:GRAPH_CLIENT_ID = '...'
$env:GRAPH_TENANT_ID = '...'
$env:GRAPH_CLIENT_SECRET = '...'
$env:GRAPH_MAILBOX_ADDRESS = '...'
$env:ENTRAID_TENANT_ID = '...'
$env:ENTRAID_CLIENT_ID = '...'
$env:ENTRAID_CLIENT_SECRET = '...'
$env:INITIAL_ADMIN_EMAILS = '...'
docker compose up

This runs dotMARC and a PostgreSQL 18 database together, with Postgres data persisted in a named Docker volume (dotmarc-postgres-data). Set the required environment variables from the setup steps above (or put them in a .env file next to docker-compose.yml, compose reads that automatically). INITIAL_ADMIN_EMAILS is how you set the InitialAdmins__Emails config value described above via Docker Compose specifically, docker-compose.yml maps this shell variable (INITIAL_ADMIN_EMAILS) onto the InitialAdmins__Emails app setting, so the naming differs in casing/format even though it's the same setting.

Reverse proxy / TLS termination​

The container listens on plain HTTP on port 8080; it expects a TLS-terminating reverse proxy (nginx, Traefik, an Azure/AWS load balancer, etc.) in front of it, forwarding X-Forwarded-For and X-Forwarded-Proto. Without this, sign-in fails with AADSTS50011 because the redirect URI sent to Entra doesn't match the https:// one registered on the dashboard app registration.

Point each monitored domain's DMARC record's rua= tag at the same mailbox this app polls, e.g.:

v=DMARC1; p=quarantine; rua=mailto:[email protected]

Next: Local Development to run and test the app from source, or Deploy to Azure to run it in production.
